Main Range of product Modicon Momentum automation platform Product or component type M1/M1E processor adaptor Concept Transparent Ready Level or class Class B10 Software designation Concept version V2.6 Modsoft version >= V2.5 ProWORX NxT version V2.0 ProWORX 32 Communication port protocol Ethernet Modbus Processor name X 86 based (INTEL, AMD)...
Main
| Range of product | Modicon Momentum automation platform |
| Product or component type | M1/M1E processor adaptor |
| Concept | Transparent Ready |
| Level or class | Class B10 |
| Software designation | Concept version V2.6 Modsoft version >= V2.5 ProWORX NxT version V2.0 ProWORX 32 |
| Communication port protocol | Ethernet Modbus |
| Processor name | X 86 based (INTEL, AMD) IEC executive |
| Clock frequency | 50 MHz |
Complementary
| Web services | Web page loader software tool Web page loader Rack viewer Data editor |
| Ethernet service | I/O scanning Modbus TCP messaging |
| Discrete I/O processor capacity | 8192 I/8192 O |
| Memory type | 1 MB flash 544 kB RAM |
| Memory description | Program memory 18 kB LL984 Program memory 200 kB IEC Data 24 kB |
| Material | Lexan |
| Word length | 16 bit |
| [Us] rated supply voltage | 5.0 V DC +/-5 % |
| Supply | By Momentum I/O base |
| Exact time for 1 Kinstruction | 1 ms |
| Register I/O processor capacity | 26048 I/26048 O |
| I/O limit processor capacity | I/O local on Modbus |
| Number of port | 1 RS485 1 Ethernet |
| Marking | CE |
| Net weight | 0.042 kg |
Environment
| Protective treatment | TC |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 5…96 % without condensation |
| Operating altitude | 2000 m |
| Shock resistance | <= 15 gn peak 11 ms half sine wave acceleration |
| Vibration resistance | 0.75 mm d.a 1 gn |
| Product certifications | Nema type 250 UL CUL FM Class 1 Division 2 |
Contractual warranty
| Warranty | 18 months |
